Industrial High-Capacity Nut Cooling Conveyor (6' x 20')
High-Volume Thermal Management for Precision Processing
Optimized for high-temperature nut roasting and snack production lines, this cooling conveyor is engineered to halt the roasting process instantly. Featuring a massive 6-foot wide-span perforated belt, it ensures your product reaches ambient temperature uniformly, preserving crunch and quality.
⚙️ Engineering Specifications
| Feature | Technical Data |
| Footprint (L x W) | 20 Feet x 7 Feet |
| Effective Belt Width | 6 Feet (Wide-span) |
| Conveyor Belt | Premium SS304 Perforated (Food Grade) |
| Chassis Material | Durable Painted Milled Steel |
| Drive System | 2HP Gear Head Motor |
| Infeed | Integrated Charge Hopper for uniform loading |
🚀 Key Performance Features
1. Advanced Air-Flow Architecture
The SS304 Perforated Belt is the core of this system. Its high open-area ratio allows for maximum air penetration and rapid heat dissipation, ensuring that even high-density loads are cooled from the core to the surface.
2. Heavy-Duty Drive Train
Equipped with a 2HP Gear Head Motor, this system is built for 24/7 continuous industrial operation. The high-torque configuration ensures consistent belt speed even under maximum product load, preventing motor fatigue.
3. Integrated Volumetric Feeding
The included Charge Hopper acts as a buffer and distributor. It ensures a consistent bed depth across the full 6-foot width of the belt, eliminating "hot spots" caused by uneven product piling.
4. Robust Structural Integrity
The frame is constructed from high-grade Milled Steel, finished with industrial-grade paint for corrosion resistance. This provides a vibration-dampened, stable platform for long-term mechanical reliability.
🛠 Integration & Customization
Application: Ideal for Peanuts, Cashews, Almonds, and Extruded Snacks.
Modular Design: Easily integrates into existing roasting or seasoning lines.
⚠️ System Note: To achieve rated cooling efficiency, Suction Blowers and Duct Lines are required. These are quoted separately based on your specific facility layout and CFM requirements.
Looking for a custom configuration? > Our engineering team can adapt the belt speed and hopper capacity to match your specific roasting output.
