(BL010300M) Blower 1KW/1.5HP 2800RPM 600CFM MS

🏷️ Blower Identification

Parameter	Technical Specification
Model Series	BL010300M
Blower Type	Centrifugal - Backward Curved
Impeller Diameter	300 mm
Blade Profile	8-Blade / 55° Backward Angle
Housing Scroll OD	390 mm
Design Verification Date	February 2026

🌬️ Performance Specifications

Metric	Rated Value
Rated Speed	2800 RPM
Maximum Airflow	700 CFM (1223 $m^3/h$)
Operating Pressure	14.2 mbar (145 mm WG)
Outlet Velocity	15.1 m/s
Inlet / Outlet Size	Ø 150 mm / 150 x 150 mm

⚡ Motor & Drive Data (Direct Drive)

Parameter	Specification
Motor Power	1.5 HP (1.1 kW)
Mounting	Flange Mount (Direct Shaft)
Full Load Amps (FLA)	9.2 A (230V) / 2.6 A (415V)
Starting Torque	3.12 N·m (Minimum Required)
Duty Cycle	S1 (Continuous)
Insulation Class	Class F
